Uninterruptible Power Supply (UPS)

Reliability of power sources is an increasing challenge in many sectors and battery-backed uninterruptable power supplies (UPS) are one option to protect and keep electronic equipment operating in the event of grid power failure. The three major UPS configurations are offline (also called standby and battery backup), line-interactive and online double conversion. While online systems are the most complex and costly, they provide waveform conditioning during normal mains supply and are even becoming bidirectional to connect to smart grids. To deliver all of this, UPS systems have become more reliable and offer greater availability while reducing energy losses and costs with the move to transformerless and modular systems.

Block diagram

設計考慮因素

  • 開始采用PWM驅動無刷直流電機控制
  • 電機驅動MOSFET必須以低RDSon和良好的熱阻抗來滿足峰值高電流需求
  • 如果過載情況會降低電池和柵極電壓,則可能需要具有強線性模式性能的MOSFET來提供反向電池保護
  • MOSFET可能需要滿足UL2595等的具體間距要求
  • 為小尺寸優(yōu)化的電荷平衡MOSFET,通常裝在可移動電池組中——每個電池一個

MOSFET and GaN FET Handbook

Drawing on over 20 years’ of experience, the MOSFET and GaN FET Application Handbook: A Power Design Engineer’s Guide brings together a comprehensive set of learning and reference materials relating to the use of MOSFETs and GaN FETs in real world systems.

Download your copy today
